Description
This entry alert system uses photo electric sensors to alert you to customers, visitors or intruders entering your property, store or home. The kit is easy to install and will sound either a ding-dong chime or sound a siren when the photo beam is broken. Use it in a variety of applications from garage door safety sensors to door alarms.
With a range of up to 22 feet, the retro-reflective photoelectric sensor signals the chime unit instantly when its wide path is crossed. The chime's speaker volume can be adjusted or turned off with the flip of a switch, and in siren mode, the sounding time is adjustable from 3 to 30 seconds. Unlike many door chime systems, there's no hard wiring required to install the IR Entry Alert System: With a range of up to 22 feet, the retro-reflective photoelectric sensor signals the chime unit instantly when its wide path is crossed. The chime's speaker volume can be adjusted or turned off with the flip of a switch, and in siren mode, the sounding time is adjustable from 3 to 30 seconds. Unlike many door chime systems, there's no hardwiring required to install the IR Entry Alert System: All components simply plug into one another, and mounting brackets and a power adapter are included in the kit.
For indoor use only.- Reflector
- Transmitter/Receiver
- Speaker/Electronic Chime
- 9V DC adapter
- Mounting brackets
- Instructions
- Dimensions - Sensor: 2 3/8" x 2 13/16" x 1 3/16"; Chime: 2 3/8" x 2 3/4" x 1 5/16"
- Sensing Range: 22' (7m)
- Supply Voltage: Sensor: 9-15 VDC, Chime: 12VDC
- Total Current Drain: 100mA Max.
- Standby Current: 25mA Max.
- Light Source: IR LED
- Control Output: Relay (AC 120V/DC 24V, 2A)
- Ambient Temperature: -4º F (-4º - 20º C) ~ 122º F (50º C)
- Speaker Response Time: ~1 sec. for Chime, 30 sec. for Alarm
- Speaker Volume: Adjustable from 0 ~ max.
- Alarm Time Range: Adjustable 3~30 sec. for alarm
- External Chime Output: Ground output (100mA)
- Speaker Output: Chime/Off/Alarm (selectable via switch)
